SPARKHOBBY SW22HV 68g Waterproof Winch Steering Servo Programmable Turn 1.5~7T Digital High Voltage Metal Gear for RC Sailing Boat (with 4T Metal Winch)

Description

• High performance programmable digital standard sail winch servo for competitions
• High precision metal gears,Double ball bearings
• High quality coreless motor,Suitable for the same class as the IOM,Waterproof

Item: SW22HV Metal Gear Hollow Cup Waterproof Steering Servo
Parameters:
Node: SW22HV
Gear: Metal
Spline: 25T
Motor: coreless motor
Bearing: 2BB
Dead band: 2us by default
Waterproof: Yes
Operating voltage: DC5.0 ~ 8.4V
Operating frequency: 1520us / 330hz
Spin: 1 ~ 7T (programmable)
Operating speed (5.0V): 0.62 seconds / 360 degrees
Operating speed (6.0V): 360 seconds / degrees
Operating speed (7.4V): 0.43 seconds / 360 degrees
Operating speed (8.4V): 0.37 seconds / 360 degrees
Stall Torque (5.0 V): 14.3 kg.cm (198.62 oz / in)
Stall Torque (6.0 V): 17.8 kg.cm (247.24 oz / in)
Stall torque (7.4V): 22.0 kg.cm (305.58 oz / in)
Stall torque (8.4V): 24.6 kg.cm (341.69 oz / in)
Dimensions: 40.5 x 20.2 x 39.5mm / 1.57 x 0.78 x 1.97in
Weight: 68g (2.39oz)
Connector cable length: JR270mm (10.53in)

Package Included:
Choose by yourself the product you need x 1
